Ask Us About This Product- Compact Integrated Amplifier
- 30w per channel at 8Ω
- 2 Line Inputs and Integrated MM Phono Stage
- Remote control
The all new io amplifier is designed with every music lover in mind. Simple to setup and operate the io is designed to integrate seamlessly into any hi-fi system.
The compact size allows it to be used in a variety of systems and delivers a performance well beyond its price point. As you would expect, there is a high quality built in moving magnet phono stage, two line level inputs, a new design remote control handset and high quality headphone output that is cleverly integrated to deliver optimum performance without compromising the audio circuit. All of these features combine to deliver a powerful, well balanced musical performance at an incredible price.
Importantly the io uses the same power amplifier and phono stage as its larger brother the multi-award winning Brio. The io aims to deliver exceptional sound quality in a smaller and more cost effective package whilst still utilising high quality audio components not expected at this price point.
The class A/B circuit shares it’s DNA with the rest of Rega’s amplifiers, and as usual great care has been taken in component selection. Their engineers have used Sanken output transistors, an Alps volume potentiometer and a linear power supply that enables an output of 30 watts per channel into 8 ohms. Two line level inputs and a high quality moving magnet phono input are available for sources. There is a headphone output provided on the front of the unit for powering standard hi-fi headphones; this is driven from the power amplifier stage of the unit through relays to avoid signal degradation when headphones are inserted or the product is muted.
Grahams recommend you partner this amplifier with:
Please contact us to arrange a demonstration.
Specifications
Input sensitivities for rated output level:
Input 1 (phono) input sensitivity = 2.1mV at 47KΩ in parallel with 220pF.
Maximum Input 1 (phono) input level = 100mV
Input 2-5 (line) input sensitivity = 210mV at 47kΩ
Maximum input 2-5 (line) input level = 10.25V
Power outputs at 230/115V supply voltage:
50 Watts RMS both channels driven into the rated load of 8Ω
58 Watts RMS one channel driven into the rated load of 8Ω
73 Watts RMS both channels driven into the rated load of 4Ω
93 Watts RMS one channel driven into the rated load of 4Ω
Continued high level use into 4Ω may cause the case to exceed 40° C above the ambient temperature.
Headphone output:
No load = 8V
32Ω = 1.8V
54Ω = 2.6V
300Ω = 5.9V
Source impedance = 109Ω
Power consumption:
135 W @ 230 V / 220 V / 115 V / 100 V into the rated load of 8 Ω
Frequency response:
Phono 15Hz to 40KHz (-3dB Points) / 27Hz to 20.5KHz (-1dB Points)
RIAA accuracy (100Hz to 10KHz) ± 0.4dB typically better than ± 0.3dB
Line 12Hz (-1dB points) to 43KHz (-3dB points)
Remote control batteries included – 2 x AAA Alkaline.
Dimensions W X D X H:
180mm x 290mm x 68mm
Weight:
2.9kg
