Ask Us About This Product- 2-way shelf or stand mount loudspeakers
- Carbon Dome™ tweeter
- Continuum cone midrange from 800 series
- Flowport™ vent
Life-sized acoustics
The powerful 706 S3 is the ideal stand-mount loudspeaker for delivering exceptional sound in larger spaces.
Sharper detail
Carbon Dome tweeters are purpose-built for the 700 Series. Delivering a dramatic improvement on the aluminium double dome tweeter, they raise the breakup threshold to 47kHz, for pinpoint imaging accuracy and detail.
Truly amazing sound
Thanks to its composite construction, the Continuum™ cone avoids abrupt transitions in behaviour that can impair the performance of a conventional drive unit. The result is a more open, neutral performance that delivers voices and instruments with precision and transparency.
Inspired by greatness
The 800 Series Diamond inspires the new curved cabinet baffle and individual drive unit pods, and greatly reduces cabinet colouration, ensuring a cleaner, more immersive sound.
Grahams recommend you partner these speakers with:
Please contact us to arrange a demonstration.
Technical Specifications:
| Technical features | Decoupled Carbon Dome tweeter Continuum™ cone bass / midrange Flowport™ |
| Description | 2-way vented-box system |
| Drive units | 1x ø25mm (1 in) Decoupled Carbon Dome high-frequency 1x ø165mm (6.5 in) Continuum cone bass / midrange |
| Frequency range | 45Hz - 33kHz |
| Frequency response | 50Hz - 28kHz ±3dB |
| Sensitivity | 88dB spl (2.83Vrms, 1m) |
| Harmonic distortion | 2nd and 3rd harmonics (90dB, 1m on axis) <1% 100Hz - 22kHz <0.5% 150Hz - 20kHz |
| Nominal impedance | 8Ω (minimum 3.7Ω) |
| Recommended amplifier power | 30W - 120W into 8Ω on unclipped programme |
| Max recommended cable impedance | 0.1Ω |
| Dimensions | Height: 345mm cabinet only Width: 192mm cabinet only Depth: 297mm cabinet only, 334mm including grille and terminals |
| Weight | 8.42kg |
|
FINISHES |
|
| Cabinet finishes | Gloss Black Satin White Mocha |
| Grille finishes | Black Grey (Satin White only) |
