NAIT XS 2 Integrated Amplifier

Integrated Amplifiers by Naim
NAIT XS 2 Integrated Amplifier
NAIT XS 2 Integrated Amplifier
NAIT XS 2 Integrated Amplifier
< >
NAIT XS 2 Integrated Amplifier
NAIT XS 2 Integrated Amplifier
NAIT XS 2 Integrated Amplifier


NAIT XS 2 Integrated Amplifier

  • High performance integrated amplifier
  • 70W per channel power output
  • Six inputs with support for both DIN and RCA connections
  • 1/4” (6.35mm) headphone output
  • Ceramic heat sink isolation
  • Powered input for use with StageLine or SuperLine phono stages

The Nait XS 2 offers much of the performance of the reference quality Naim SuperNait 2 in a simpler, slimmer package combining a 70W power amplifier with six analogue inputs. Its high performance pre-amplifier is as transparent as you would expect from a Naim Audio amplifier, and it also shares the single-ended class-A headphone output of its larger sibling.

The NAIT XS 2 can be upgraded with a Naim HiCap DR external power supply. The analogue delights of vinyl are yours to explore: simply add a Naim StageLine or Naim SuperLine phono stage.

The NAIT XS 2 is both powerful and delicate, dynamic and even-handed. It does everything the music asks and delivers everything that a Naim Audio amplifier should.

Grahams recommend you partner this amplifier with:

Please contact us to arrange a demonstration.

Technical Specifications:

Audio Inputs
Input Sensitivity 130mV
Input Impedance 47kΩ
Analogue Input 4 x DIN/RCA pair, 1 x RCA pair, 1 x DIN (for Naim phono amplifier)

Audio Outputs
Line Outputs Fixed (level) 130mV, 600Ω
Line Outputs Variable (level) 775mV, <50Ω
Power Outputs Naim phono amplifier
Audio Outputs Speakers, record, preamp and variable sub
Other Outputs Headphone, 1/4" jack

Speaker Outputs
Power Output 70W/channel, 8Ω

Remote Control Infra Red (RC5)
Remote Input 1 x 3.5mm jack on rear (RC5 modulated/unmodulated)
Updates 1 x USB Type Mini-B

User Control
Front Panel Volume Control, seven button matrix

Mains Supply 100V, 115V, 230V; 50 or 60Hz
Power Consumption (quiescent) 20VA
Power Consumption (max.) 290VA (max.)

Dimensions (HxWxD) 70 x 432 x 301 mm
Weight 8.4 kg
Shipping Dimensions 200 x 590 x 500 mm
Shipping Weight 10.35 kg
Supplied with NARCOM-4 Remote Control

Front Brushed and black anodised
Case Black powder coated
